JDX MBY reducer is aimed to the large input power specifically for cement and other industries, large input torque, low speed, impact load is serious, continuous operation and harsh working conditions design. Designed to fully absorb the advantages of similar products at home and abroad, summed up the domestic and international experience in the design and manufacture of the product, the use of modern gear design, manufacturing technology, making the series reducer with a safe, reliable, long service life, widely used cement mill on the edge of the drive, the coal grinding mill.

Transmission:single-edge
Material:low-carbon alloy steel
Hardness:54-62HRC
Precision:sixth grade(ISO1328)
Working temperature: -40~50°C. the lubrication should be heated until about 0°C if the machine works below 0°C.
The working place should be lower than 1,000 meters above sea level.
The input rotational speed should not exceed 1800 r/min. The circumferential speed of the gear should not exceed 20 m/s.
Suitable for normal-reverse rotation.
Without in

dustry limitation.Please consult our technical supporting department for other circumstances.
